OmniVision / OV7692 1/13" Color CMOS VGA (640x480) Image Sensor with OmniPixel3-HS Technology
Features
VGA output
High sensitivity >12 V/(lux-sec)
Automatic exposure/gain with 16 zone control
Horizontal and vertical windowing capability
Auto white balance control
Aperture/gamma correction
External frame sync capability (Genlock)
Slave compatible serial camera control bus (SCCB) control interface for register programming
Low power consumption
Extremely low dark current for high temperature applications
50/60 Hz flicker cancellation
Overlay with four layers, 16 colors and eight transparencies each
16 bytes of one-time programmable memory (OTP) to control overlay and set other customer variables
SPI master for single static overlay and loading setting
Dynamic overlay controls
Defective pixel correction
