OmniVision / OV7738 1/7.5" Color CMOS VGA (640x480) Image Sensor with OmniPixel3 Technology
Features
SMIA profile level 0 compatible
CCP2, class 0 interface with up to 208 Mbps data transfer rate
Supports free-running clock and gated clock
Supports data/clock and data/strobe signaling
Supports global analog gain
High sensitivity and low dark current for low-light conditions
Low operating voltage and low power consumption for embedded portable applications
Supports down sample mode and VarioPixel®
Auto black level calibration
Defect correction capability
CCI for flexible function control
Programmable gain boost up to +30 dB (32x max)
